| 1 | B00508+ZL20-030101A | 通风器盖 ventilator cover | 1 |
| 2 | GBT39-M6-5-A3L | 方螺母 square nut | 1 |
| 3 | B00508+ZL20-030103 | 通风器通风片 ventilator fan | 1 |
| 4 | B00508+ZL20-030105A | 通风器隔套 ventilator spacing sleeve | 1 |
| 5 | B00508+ZL20-030106 | 通风器迷宫片 ventilator piece | 5 |
| 6 | B00508+ZL20-030107A | 铜隔套 cotter spacing sleeve | 4 |
| 7 | B00508+ZL20-030102 | 通风器长螺丝 Long screw of ventilator | 1 |
| 8 | B00508+ZL20-030109B | 通风器壳体 ventilator housing | 1 |
| 1 | GBT5783-M8X16-8.8-A3L | 六角头螺栓 Hex bolt | 2 |
| 2 | B00508+ZL20—032001 | 止动垫 stop gasket | 1 |
| 3 | B00508+ZL20—032002A | 轴端挡板 shaft end baffle | 1 |
| 4 | B00508+cA10-350914A | 活塞环 piston ring | 2 |
| 5 | B00508+ZL20-032003 | 内封油套 Inner oil seal sleeve | 1 |
| 6 | GBT297-32207 | 圆锥滚子轴承 Tapered roller bearing | 2 |
| 7 | B00508+ZL20-036001 | 轴套 shaft bush | 1 |
| 8 | B00508+ZL20-032009 | 闷塞 plug | 1 |
| 9 | B00508+ZL20-036003 | 倒档轴 Reverse gear shaft | 1 |
| 10 | GBT893.2—75 | 孔用弹性挡圈 circlip for hole | 2 |
| 11 | B00508+ZL20—036002X1 | 齿轮(Z=49) Gear (Z=49) | 1 |
| 12 | B00508+ZL20—032100 | 离合器总成 clutch assembly | 1 |
| 13 | B00508+ZL20—036004X1 | 齿轮(Z=44) Gear (Z=44) | 1 |
| 14 | B00508+ZL20—032006 | 止动垫 stop gasket | 4 |
| 15 | GBT5783—M10X25—8.8—A3L | 六角头螺栓 Hex bolt | 8 |
| 16 | GBT119.1—8m6X22—A0p | 圆柱销 column pin | 2 |
| 1 | GBT5783-M8X16-8.8-A3L | 六角头螺栓 Hex bolt | 2 |
| 2 | B00508+ZL20—032001 | 止动垫 stop gasket | 1 |
| 3 | B00508+ZL20—032002A | 轴端挡板 shaft end baffle | 1 |
| 4 | B00508+cA10-350914A | 活塞环 piston ring | 2 |
| 5 | B00508+ZL20-032003 | 内封油套 Inner oil seal sleeve | 1 |
| 6 | GBT297-32207 | 圆锥滚子轴承 Tapered roller bearing | 2 |
| 7 | B00508+ZL20-033001X1 | 齿轮(Z=24) Gear (Z=24) | 1 |
| 8 | B00508+ZL20-032009 | 闷塞 plug | 1 |
| 9 | B00508+ZL20-033002 | 中间轴 Intermediate shaft | 1 |
| 10 | GBT893.2—75 | 孔用弹性挡圈 circlip for hole | 2 |
| 11 | GBT276—6009 | 深沟球轴承 Deep grooved ball bearing | 2 |
| 12 | B00508+ZL20—033004X1 | 齿轮(Z=41) Gear (Z=24) | 1 |
| 13 | B00508+ZL20—032100 | 离合器总成 clutch assembly | 1 |
| 14 | B00508+ZL20—033005X1 | 齿轮(Z=54) Gear (Z=24) | 1 |
| 15 | B00508+ZL20—032006 | 止动垫 stop gasket | 4 |
| 16 | GBT5783—M10X25—8.8—A3L | 六角头螺栓 Hex bolt | 8 |
| 17 | GBT119.1—8m6X22—A0p | 圆柱销 column pin | 2 |
B00508+ZL20-033000×1 中间轴总成 Intermediate shaft Assembly
B00508+ZL20-032100 离合器总成 clutch Assembly
| 1 | GBT894.2—60 | 轴用弹性挡圈 circlip for shaft | 1 |
| 2 | B00508+ZL20—032101 | 挡圈 snap ring | 1 |
| 3 | B00508+ZL20—032102 | 外端盖 。uter end cover | 1 |
| 4 | B00508+1201—0007A | 外摩擦片 。uter friction disc | 6 |
| 5 | B00508+ZL20—032103 | 内摩擦片 Inner friction disc | 5 |
| 6 | B00508+ZL20—032110 | 弹赁座 spring seat | 1 |
| 7 | B00508+ZL20—032108 | 弹赁(8.0x87x80) spring (8.0x87x80) | 1 |
| 8 | B00508+ZL20—032106 | 活塞 piston | 1 |
| 9 | B00508+ZL20—032107 | 封油圈 。il seal ring | 1 |
| 10 | B00508+ZL20—32105 | 离合器壳体总成 clutch housing assembly | 1 |
| 11 | GBT308—5—G100—b | 钢球 steel ball | 1 |
| 12 | B00508+ZL20—032109 | 阀座 valve seat | 1 |
B00508+ZL20-030072-77 输出轴总成 。utput shaft assembly
| 1 | GBT5783-M10X25-8.8-A3L | 六角头螺栓 Hex bolt | 4 |
| 2 | B00508+ZL20—030077 | 止动垫 stop gasket | 2 |
| 3 | B00508+ZL20—030078 | 压板 Press plate | 2 |
| 4 | B00508+Q26-01-52X5.7 | 密封环 seal ring | 2 |
| 5 | B00508+ZL20—030013B—1 | 输出法兰总成 。utput flange assembly | 2 |
| 7 | GBT9877.1—FB65X90X12 | 唇形密封圈 Lip-shape 。-ring | 4 |
| 8 | B00508+ZL20—030071 | 输出轴后端盖 Rear end cover of output shaft | 1 |
| 9 | GBT5783—M10X30—8.8—A3L | 六角头螺栓 Hex bolt | 8 |
| 10 | GBT93—10—A0P | 标准型弹赁垫圈 standard spring washer | 8 |
| 11 | GBT276—6310 | 深沟球轴承 Deep—groove ball bearing | 2 |
| 12 | B00508+ZL20—030010A | 止推环 stop ring | 2 |
| 13 | B00508+sF—15530 | 滑动轴承 sliding bearing | 4 |
| 14 | B00508+ZL20—030009X1 | 齿轮(输出轴高速档) Gear (high-speed shift of output shaft) | 1 |
| 15 | B00508+ZL20—030019 | 高低档滑动齿套 sliding gear of high—low gear | 1 |
| 16 | GBT308—4—G24—b | 钢球 steel ball | 2 |
| 17 | B00508+ZL20—030072A | 输出轴 。utput shaft | 1 |
| 18 | B00508+ZL20—030021X1 | 齿轮 Gear | 1 |
B00508+ZL20-032000×1 输入轴总成 Input shaft Assembly
| 1 | GBT810-M20X1.5 | 小圆螺母 small round nut | 1 |
| 2 | GBT858-20 | 圆螺母用止动垫圈 Thrust washer for round nut | 1 |
| 3 | GBT97.1-20-A0P | 平垫圈 Flat washer | 1 |
| 4 | B00508+ZL20-030061X4 | 凸缘总成 Flange assembly | 1 |
| 5 | GBT297-32207 | 圆锥滚子轴承 Tapered roller bearing | 2 |
| 6 | B00508+ZL20-032008 | 输入轴 Input shaft | 1 |
| 7 | B00508+ZL20-032009 | 闷塞 Plug | 1 |
| 8 | GBT893.2-75 | 孔用弹性挡圈 circlip for hole | 2 |
| 9 | GBT276-6009 | 深沟球轴承 Deep grooved ball bearing | 2 |
| 10 | B00508+ZL20-032007X1 | 齿轮(Z=33) Gear (Z=33) | 1 |
| 11 | B00508+ZL20-032100 | 离合器总成 clutch assembly | 1 |
| 12 | B00508+ZL20-032010X1 | 输入轴齿轮(Z=46) Input shaft gear (Z=46) | 1 |
| 13 | B00508+ZL20-032006 | 止动垫 stop gasket | 4 |
| 14 | GBT5783-M10X25-8.8-A3L | 六角头螺栓 Hex bolt | 8 |
| 15 | GBT119.1-8m6X22-A0P | 圆柱销 column pin | 2 |
| 16 | B00508+ZL20-032004 | 轴套 shaft bush | 1 |
| 17 | B00508+ZL20-032003 | 内封油套 Inner oil seal sleeve | 1 |
| 18 | B00508+cA10-350914A | 活塞环 Piston ring | 2 |
| 19 | B00508+ZL20-032002A | 轴端挡板 shaft end baffle | 1 |
| 20 | B00508+ZL20-032001 | 止动垫 stop gasket | 1 |
| 21 | GBT5783-M8X16-8.8-A3L | 六角头螺栓 Hex bolt | 2 |
B00508+ZL20-030044-55 高低档拨叉机构 High-low gear shift fork mechanism
| 1 | B00508+tiesi | 铁丝 Iron wire | 1 |
| 2 | B00508+ZL20-030049 | 紧定螺钉 Fastening screw | 1 |
| 3 | B00508+ZL20-030048 | 高低换挡拨叉 High-low gear shift fork | 1 |
| 4 | B00508+ZL20-030045 | 纸垫 Paper gasket | 1 |
| 5 | B00508+ZL20-030047 | 拨叉支架 shift fork trestle | 1 |
| 6 | GBT93-10-A0P | 标准型弹赁垫圈 standard spring washer | 4 |
| 7 | GBT5783-M10X30-8.8-A3L | 六角头螺栓 Hex bolt | 4 |
| 8 | JB2600-1980-sD18X35X10 | 油封 。il seal | 1 |
| 9 | B00508+ZL20-030046 | 拨叉轴 shift fork shaft | 1 |
| 10 | B00508+ZL20-030200 | 螺塞 screw plug | 1 |
| 11 | B00508+ZL20-030044 | 垫圈 washer | 1 |
| 12 | GBT308-10-G100-b | 钢球 steel ball | 1 |
B00508+ZL20-038000J 手制动器总成 Hand Brake Assembly
| 1 | B00508+JF.B.ZL20.01 | 制动支座 Brake bracket | 1 |
| 2 | B00508+JF.B.ZL20.14 | 弹赁 spring | 2 |
| 3 | B00508+sCDX—01—201 | 手制动蹄片 Hand brake shoe | 1 |
| 4 | B00508+JF.B.ZL20.06 | 拉赁销 Tension spring pin | 1 |
| 5 | GBT41—M10—5—A3L | 六角螺母 Hex nut | 2 |
| 6 | B00508+JF.B.ZL20.10 | 支柱 pillar | 1 |
| 7 | B00508+JF.B.ZL20.09 | 直销 pin | 1 |
| 8 | B00508+JF.B.ZL20.12 | 内压板 Inner press plate | 1 |
| 9 | B00508+JF.B.ZL20.04 | 外压板 。uter press plate | 1 |
| 10 | B00508+JF.B.ZL20.12 | 螺栓 Bolt | 1 |
| 11 | B00508+JF.B.ZL20.08 | 拉杆 pull rod | 1 |
| 12 | GBT6184—M10—8—A3L | 1 型全金属六角锁紧螺母 Type 1 full metal hex lock nut | 1 |
| 13 | B00508+JF.B.ZL4050.G.08.02 | 拉杆活块 pull rod block | 1 |
| 14 | B00508+JF.B.ZL4050.G.08.03 | 支承轴 support shaft | 1 |
| 15 | B00508+JF.B.ZL20.03 | 复位板赁 Retraction leaf spring | 1 |
| 16 | B00508+JF.B.ZL50HR.03 | 锁紧垫片 Lock gasket | 1 |
B00745+9D652-24AOOOOOOAO 精益变速箱总成 ZL3O-Ⅳ Jingyi gearboxy assemblyZL30-Ⅳ
| 1 | B00745+ZL30.07—00—ft | 变速箱加油管总成 Gearbox oil filling pipe assembly | 1 |
| 2 | B00745+ZL30.01—00 | 箱体部件 Gearbox body components | 1 |
| 3 | B00745+ZL30.09—00—ft | 支架 Trestle | 2 |
| 4 | B00745+ZL30.10—00 | 倒挡轴总成 Reverse gear shaft assembly | 1 |
| 5 | B00745+ZL30.04—00 | 中间轴总成 Intermediate shaft assembly | 1 |
| 6 | B00745+ZL30.02—00 | 输出轴总成 。utput shaft assembly | 1 |
| 7 | B00745+ZL30.03—00 | 输入轴总成 Input shaft assembly | 1 |
| 8 | B00745+ZL30.08—00 | 高低挡拨叉机构 High—low gear shift fork mechanism | 1 |
| 9 | B00745+ZL30.13—00 | 手制动器总成 Hand brake assembly | 1 |
| 10 | B00745+ZL428—00 | 变速操纵阀 Transmission control valve | 1 |
