B00745+ZL30.13一00 手制动器总成 Hand brake assembly
| 1 | B00745+ZL30.13—01 | 制动支座 Brake bracket | 1 |
| 2 | B00745+ZL30.13—02 | 弹赁 spring | 2 |
| 3 | B00745+ZL30.13—03 | 制动片 Brake piece | 2 |
| 4 | B00745+ZL30.13—04 | 弹赁销 spring pin | 1 |
| 5 | GBT41—M6—5—A2L | 六角螺母 Hex nut | 2 |
| 6 | B00745+ZL30.13—05 | 支柱 pillar | 1 |
| 7 | B00745+ZL30.13—06 | 直销 pin | 1 |
| 8 | B00745+ZL30.13—07 | 内压板 Inner press plate | 1 |
| 9 | B00745+ZL30.13—08 | 外压板 。uter press plate | 1 |
| 10 | B00745+ZL30.13—09 | 螺栓 Bolt | 1 |
| 11 | B00745+ZL30.13—10 | 拉杆 pull rod | 1 |
| 12 | GBT6184—M8—8 | 1 型全金属六角锁紧螺母 Type 1 full metal hex lock nut | 1 |
| 13 | B00745+ZL30.13—11 | 拉杆活块 pull rod block | 1 |
| 14 | B00745+ZL30.13—12 | 支承轴 support shaft | 1 |
| 15 | B00745+ZL30.13—13 | 复位板赁 Retraction leaf spring | 1 |
| 16 | B00745+ZL30.13—14 | 锁紧垫圈 Lock gasket | 1 |
| 17 | B00745+ZL30.13—15 | 锁紧螺栓 Lock bolt | 2 |
B00745+ZL428-00 变速箱操纵阀总成 Gearbox control valve assembly
| 1 | B00745+Z320471200 | 螺钉(M12X1.25) screw (M12X1.25) | 1 |
| 2 | JB1002-1977-12 | 组合垫 compound gasket | 1 |
| 3 | B00745+Z320471190 | 弹赁(定位赁) spring (location spring) | 1 |
| 4 | GBT308-9.5-G200-b | 钢球 steel ball | 1 |
| 5 | B00745+siduZ1/8 | 丝堵 Z1/8 Pipe plug Z1/8 | 1 |
| 6 | JB1002-1977-10 | 组合垫 compound gasket | 1 |
| 7 | B00745+ZL428-09 | 螺塞 M10X1-6h screw plug M10X1-6h | 1 |
| 8 | GBT893.1-30 | 孔用弹性挡圈 circlip for hole | 2 |
| 9 | B00745+HG4-692-67-PD14X30X10 | 油封 。il seal | 2 |
| 10 | B00745+HG4-692-67-PD14X30X8 | 油封 。il seal | 2 |
| 11 | B00745+Z320471180 | 垫圈 washer | 2 |
| 12 | B00745+Z320471300 | 操纵阀杆 control valve rod | 1 |
| 13 | B00745+Z428-10 | 进气接头 Air inlet joint | 1 |
| 14 | GBT3452.1-22X2.4G | 。形橡胶密封圈 。-ring | 1 |
| 15 | B00745+ZL428-11 | 皮碗 Rubber cup | 1 |
| 16 | B00745+ZL428-12 | 制动滑阀 Brake sliding valve | 1 |
| 17 | B00745+ZL428-13 | 弹赁 spring | 1 |
| 18 | GBT3452.1-16X2.4G | 。形橡胶密封圈 。-ring | 1 |
| 19 | B00745+ZL428-14 | 弹赁座 spring seat | 1 |
| 20 | B00745+ZL428-15 | 螺塞 screw plug | 1 |
| 21 | B00745+ZL428-02 | 阀体 valve body | 1 |
| 22 | B00745+ZL428-03 | 垫片 Gasket | 1 |
| 23 | B00745+ZL428-01 | 底板 Bottom board | 1 |
| 24 | GBT70.1-M6X16-8.8-A2L | 内六角圆柱头螺钉 socket hexagonal cap head screw | 15 |
| 25 | B00745+ZL30-030034 | 纸垫 Paper gasket | 1 |
| 26 | GBT5782-M10X50-8.8-A3L | 六角头螺栓 Hex bolt | 8 |
| 27 | GBT93-10-A0P | 标准型弹赁垫圈 standard spring washer | 8 |
9D65O-25AOOOOOOAO 传动轴安装 Transmission shaft assembling
| 1 | 9D650-25A000001A0 | 螺栓 M12X1.5X35 Bolt M12X1.5X35 | 4 |
| 2 | SPL-CO-M12X1.5-10-F3 | 六角头凸缘螺母 Hex flange nut | 8 |
| 3 | 9D650-25A050000A0 | 主传动轴总成 Main transmissions shaft assembly | 1 |
| 4 | 9D650-25A040000A0 | 后传动轴总成 Rear transmission shaft assembly | 1 |
| 5 | SPL-CO-M14X1.5-10-F3 | 六角头凸缘螺母 Hex flange nut | 24 |
| 6 | 9D650-25A000002A0 | 螺栓 M14X1.5X45 Bolt M14X1.5X45 | 20 |
| 7 | 9D650-25A000003A0 | 螺栓 M14X1.5X55 Bolt M14X1.5X55 | 4 |
| 8 | 9D650-25A030000A0 | 中间传动轴总成 Middle transmissions shaft assembly | 1 |
| 9 | 9D650-25A020000A0 | 中间支撑总成 Middle support assembly | 1 |
| 10 | GBT5783—M16X40-A3L | 六角头螺栓 Hex bolt | 4 |
| 11 | GBT93-16-A0P | 标准型弹赁垫圈 standard spring washer | 4 |
| 12 | 9D650-25A010000A0 | 前传动轴总成 Front transmission shaft assembly | 1 |
B02313+9D650-25A010000A0 前传动轴总成 weifang yuandong front transmission shaft assembly
B02313+9D650-25A030000A0 中间传动轴总成 weifang yuandong middle transmission shaft assembly
B02313+9D650-25A030000A0 中间传动轴总成 weifang yuandong middle transmission shaft assembly
B02313+9D650-25A040000A0 后传动轴总成 weifang yuandong rear transmission shaft assembly
B02313+9D650-25A050000A0 主传动轴总成 weifang yuandong main transmission shaft assembly
B02313+9D650-25A050000A0 主传动轴总成 weifang yuandong main transmission shaft assembly
9D65O-26COOOOOOBO 前驱动桥安装 Front drive axle assembly
| 1 | 9D650-26C010000B0 | 前驱动桥总成 Front drive axle assembly | 1 |
| 2 | GBT5785-M24X2X220-10.9-A2L | 六角头螺栓 Hex bolt | 8 |
| 3 | GBT889.2-M24X2-A9L | I型非金属嵌件六角锁紧螺母 Type 1 hexagon lock nut with non-metallic inserts | 8 |
| 4 | 9F850-27A020000A0 | 弧板摩擦片 square plate friction disc | 4 |
B00256+9D650-26C010000B0 徐州美驰前桥总成 xPRC1132D027 xuzhou Meichi front axle assembly xPRC1132D027
| 1 | B00256+83351200 | 轮边减速器总成 wheel hub reducer assembly | 2 | |
| 2 | B00256+84688301 | 制动钳 Brake caliper | 2 | |
| 3 | B00256+81350100 | 桥壳总成 Axle housing assembly | 1 | |
| 4 | B00256+82350200 | 前主减速器总成 Front main reducer assembly | 1 | |
| 5 | B00256+75500159 | 螺栓 M10X40 Bolt M10X40 | 4 | |
| 6 | B00256+52020003 | 垫圈 10 washer 10 | 11 | |
| 7 | B00256+75500151 | 螺栓 M10X30 Bolt M10X30 | 7 | |
| 8 | B00256+75500225 | 螺柱 M10X50 stud M10X50 | 3 | |
| 9 | B00256+75500681 | 固定圆锥套 Fixing taper sleeve | 3 | |
| 10 | B00256+51014003 | 螺母 M10 Nut M10 | 3 | |
| 11 | B00256+52000002 | 垫圈 10 washer 10 | 2 | |
| 12 | B00256+51010007 | 螺母 M20X1.5 Nut M20X1.5 | 24 | |
| 13 | B00256+52020008 | 垫圈 20 washer 20 | 36 | |
| 14 | B00256+79900437 | 轮鋼螺母 Rim nut | 24 | |
| 15 | B00256+79900439 | 轮鋼螺栓 Rim bolt | 24 | |
| 16 | B00256+75500197 | 螺塞 M24X1.5 screw plug M24X1.5 | 2 | |
| 17 | B00256+53200005 | 组合密封垫 compound seal gasket | 2 | |
| 18 | B00256+56100001 | 通气塞 vent plug | 1 | |
| 19 | B00256+80214001 | 半轴 Half axle | 2 | |
| 20 | B00256+72006561 | 制动盘 Brake disc | 2 | |
| 21 | B00256+75502011 | 螺栓 M18X2X40 Bolt M18X2X40 | 32 | |
| 22 | B00256+52020007 | 垫圈 18 washer 18 | 32 | |
| 23 | B00256+75502139 | 螺栓 M20X60 Bolt M20X60 | 4 | |
| 24 | B00256+50009039 | 螺栓 M20X60 Bolt M20X60 | 8 |
B00256+83351200 轮边减速器总成 Hub Reducer Assembly
| 1 | B00256+79900467 | 行星轮架总成 planet carrier assembly | 1 |
| 1.1 | B00256+50160003 | 螺钉 M8X15 screw M8X15 | 3 |
| 1.2 | B00256+83240205 | 行星轮轴 planet gear shaft | 3 |
| 1.3 | B00256+83240204 | 行星轮 planet gear | 3 |
| 1.4 | B00256+83021511 | 隔套 spacing sleeve | 3 |
| 1.5 | B00256+83240211 | 行星轮垫 planet gear gasket | 6 |
| 1.6 | B00256+54400006 | 滚针 6X21.8 Rolling needle 6X21.8 | 126 |
| 1.7 | B00256+83240201 | 行星轮架 planet carrier | 1 |
| 1.8 | B00256+83240206 | 限位块 Limitation block | 1 |
| 2 | B00256+52100009 | 挡圈 circlip | 1 |
| 3 | B00256+83240203 | 太阳轮 sun wheel | 1 |
| 4 | B00256+52060005 | 垫圈 75 washer 75 | 1 |
| 5 | B00256+71270231 | 螺母 M75X2 Nut M75X2 | 2 |
| 6 | B00256+51270006 | 销 12X24 pin 12X24 | 2 |
| 7 | B00256+77000081 | 锥套 Taper sleeve | 1 |
| 8 | B00256+83021509 | 油封座 。il seal seat | 1 |
| 9 | B00256+83021510 | 挡油板 。il baffle | 1 |
| 10 | B00256+53500013 | HMs4 油封 140X170X15 HMs4 oil seal 140X170X15 | 1 |
| 11 | B00256+53100005 | 油封 FB140X170X15 。il seal FB140X170X15 | 1 |
| 12 | B00256+83240202 | 轮毅 Hub | 1 |
| 13 | B00256+54100006 | 轴承 32024E Bearing 32024E | 1 |
| 14 | B00256+54100005 | 轴承 32022 Bearing 32022 | 1 |
| 15 | B00256+52020006 | 垫圈 16 washer 16 | 12 |
| 16 | B00256+50012035 | 螺栓 M16X1.5X30 Bolt M16X1.5X30 | 12 |
| 17 | B00256+53200005 | 组合密封垫 24 compound seal gasket24 | 1 |
| 18 | B00256+75500197 | 螺塞 M24x1.5 screw plug M24x1.5 | 1 |
| 19 | B00256+83240207 | 齿圈支承总成 Gear ring support assembly | 1 |
| 19.1 | B00256+83240208 | 齿圈 Gear ring | 1 |
| 19.2 | B00256+83240209 | 齿圈支承 Gear ring support | 1 |
| 19.3 | B00256+83240210 | 卡环 clamp ring | 1 |
| 20 | B00256+53200002 | 组合密封垫 12 compound seal gasket12 | 1 |
| 21 | B00256+75500842 | 螺塞 M12x1.25×9 screw plug M12x1.25×9 | 1 |
| 22 | B00256+79605020 | 调整支柱组 Adjusting brace group | 1 组 1 group |
| 23 | B00256+77000021 | 隔套 spacing sleeve | 1 |
| 24 | B00256+79500132-134 | 调整垫片组 Adjusting gasket group | 1 组 1 group |
