B00256+81350100 桥壳总成 Axle housing assembly
| 1 | B00256+79600124 | 制动钳支架 Brake caliper bracket | 2 |
| 2 | B00256+81246101 | 端轴 End shaft | 2 |
| 3 | B00256+81350101 | 桥壳 Axle housing | 1 |
B00256+82351100 主减速器总成 Main reductor assembly
| 1 | B00256+82215101 | 后主传动齿轮副 Rear main transmission gear pair | 1 |
| 1.1 | B00256+82215102 | 主动螺旋锥齿轮 Driving spiral bevel gear | 1 |
| 1.2 | B00256+82215103 | 被动螺旋锥齿轮 Driven spiral bevel gear | 1 |
| 2 | B00256+51040002 | 螺母 M12X1.25 Nut M12X1.25 | 12 |
| 3 | B00256+75500010 | 螺栓 M12X1.25 Bolt M12X1.25 | 12 |
| 4 | B00256+54000001 | 轴承 102306 Bearing 102306 | 1 |
| 5 | B00256+54100038 | 轴承 7814 Bearing 7814 | 2 |
| 6 | B00256+56000018 | 锁紧铁丝 Φ2X800 LocK iron wire Φ2X800 | 2 |
| 7 | B00256+75200100 | 调整螺母 Adjusting nut | 2 |
| 8 | B00256+53500021 | HMSA7 油封 60X80X8 HMSA7 oil seal 60X80X8 | 1 |
| 9 | B00256+53500020 | HMS4 油封 60X80X8 HMS4 oil seal 60X80X8 | 1 |
| 10 | B00256+52020004 | 垫圈 12 washer 12 | 1 |
| 11 | B00256+75500006 | 螺栓 M12X1.5X45 Bolt M12X1.5X45 | 1 |
| 12 | B00256+75500005 | 螺栓 M14X1.5X45 Bolt M14X1.5X45 | 5 |
| 13 | B00256+52020005 | 垫圈 14 washer 14 | 5 |
| 14 | B00256+75500013 | 锁紧螺母 LocK nut | 1 |
| 15 | B00256+82350201 | 连接法兰组件 connecting flange components | 1 |
| 15.1 | B00256+82350202 | 连接法兰 connecting flange | 1 |
| 15.2 | B00256+75200142 | 防尘罩 Dustproof cover | 1 |
| 16 | B00256+75203629 | 盖 cover | 1 |
| 17 | B00256+82214206 | 轴承座 Bearing seat | 1 |
| 18 | B00256+79800023 | 主减速器壳体组件 Main reducer housing components | 1 |
| 18.1 | B00256+75201054 | 主减速器壳体 Main reducer housing | 1 |
| 18.2 | B00256+75200035 | 盖 cover | 1 |
| 18.3 | B00256+75502601 | 螺栓 M22X2.5 Bolt M22X2.5 | 4 |
| 19 | B00256+54100011 | 轴承 31309 Bearing 31309 | 1 |
| 20 | B00256+79605003 | 调整垫片组 Adjusting gasKet group | 1 组 1 group |
| 21 | B00256+50004003 | 螺栓 M10X20 Bolt M10X20 | 2 |
| 22 | B00256+75200054 | 锁紧片 LocK piece | 2 |
| 23 | B00256+54100012 | 轴承 31310 Bearing 31310 | 1 |
| 24 | B00256+82666203 | 调整隔套组 Adjusting spacing sleeve unit | 1 组 1 group |
| 25 | B00256+82214207 | 差速器总成 Differential assembly | 1 |
B00256+82214207 差速器总成 Differential assembly
| 1 | B00256+79800005 | 差速器壳体组件 Differential housing components | 1 |
| 1.1 | B00256+82190102 | 左差速器壳体 Differential left housing | 1 |
| 1.2 | B00256+82190103 | 右差速器壳体 Differential right housing | 1 |
| 2 | B00256+75201604 | 半轴齿轮垫 Half axle gear gasket | 2 |
| 3 | B00256+75201288 | 半轴齿轮 Half axle gear | 2 |
| 4 | B00256+75200088 | 十字轴 cross shaft | 1 |
| 5 | B00256+51040002 | 螺母 M12X1.25 Nut M12X1.25 | 8 |
| 6 | B00256+75201605 | 行星齿轮垫片 planet gear gasket | 4 |
| 7 | B00256+75201289 | 行星锥齿轮 planet taper gear | 4 |
| 8 | B00256+75501979 | 凸缘螺栓 Flange bolt | 8 |
9D65O-29AOOOOOOCO 停车与辅助制动系统 parking and auxiliary brake system
| 1 | 9D650-29A020000A0 | 软轴支座 soft shaft bracket | 1 |
| 2 | 9F560-29A010000A0 | 停车制动操纵机构 parking brake control mechanism | 1 |
| 3 | GBT16674.1-M10X20-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 4 |
| 4 | 9F650-29A010200A0 | 管夹 clip | 1 |
| 5 | GBT16674.1-M8X16-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 1 |
9D651-31AOOOOOOAO 变矩器变速箱油路 。il pipeline of converter gearbox
| 1 | 9D651-31A000001A0 | 变速泵吸油胶管 。il suction hose of transmission pump | 1 |
| 2 | 9D650-31A000002A0 | 变速泵吸油接头 。il suction joint of transmission pump | 1 |
| 3 | 9D651-31A010000A0 | 变速泵 Transmission pump | 1 |
| 4 | 9D650-31A000006A0 | 变速泵出油接头 。il outlet joint of transmission pump | 1 |
| 5 | JBT982-27 | 组合密封垫圈 compound seal washer | 1 |
| 6 | 9D650-31A000009A0 | 主压力阀接头 2 Main pressure valve joint 2 | 1 |
| 7 | 9D650-31A020000A0 | 过滤器进油软管 。il inlet hose of filter | 1 |
| 8 | 9D650-31A000007B0 | 过滤器接头 Filter joint | 2 |
| 9 | JBT982-33 | 组合密封垫圈 compound seal washer | 2 |
| 10 | 9D650-31A030000B0 | 低压过滤器 Low-pressure filter | 1 |
| 10.1 | 9D650-31A030100A0 | 低压过滤器壳体 Low-pressure filter housing | 1 |
| 10.2 | 9D650-31A030200A0 | 滤芯 Filter cartridge | 1 |
| 11 | QLWZG056.2-0120550 | 24。锥软管总成 24。taper hose assembly | 1 |
| 12 | GBT5783-M8X20-8.8-A2L | 六角头螺栓 Hex bolt | 2 |
| 13 | GBT93-8-A0P | 标准型弹赁垫圈 standard spring washer | 8 |
| 14 | 9D650-31A000012A0 | 过滤器安装支架 Filter installation trestle | 1 |
| 15 | GBT16674.1-M10X20-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 2 |
| 16 | GBT93-10-A0P | 标准型弹赁垫圈 standard spring washer | 2 |
| 17 | 9D650-31A000008A0 | 主压力阀接头 1 Main pressure valve joint 1 | 1 |
| 18 | 9D650-31A000005A0 | 变速泵连接套 connecting sleeve of transmission pump | 1 |
| 19 | GBT70.1-M8X20-A2L | 内六角圆柱头螺钉 Hexagon socket head cap screws | 6 |
| 20 | 9D650-31A000004A0 | 变速泵法兰 Transmission pump flange | 1 |
| 21 | GBT5783-M10X30-8.8-A3L | 六角头螺栓 Hex bolt | 2 |
| 22 | QLWZG056.2-0040830 | 24。锥软管总成 24。taper hose assembly | 1 |
| 23 | 9D650-31A000011A0 | 溢油接头 。verflow joint | 2 |
| 24 | 9D650-31A000010A0 | 较接螺栓 Joint bolt | 1 |
| 25 | JBT982-22 | 组合密封垫圈 compound seal washer | 1 |
| 26 | 9D650-31A050000A0 | 进变速阀软管 Hose into transmission valve | 1 |
| 27 | 9D650-31A070000A0 | 钢丝式喉箍 Φ48 steel-wire hoop c48 | 2 |
| 28 | 9D650-31A000003A0 | 变速泵较接螺栓 Joint bolt of transmission pump | 1 |
| 29 | 9D650-31A080000A0 | 过渡接头 Transmit joint | 1 |
9D651-32BOOOOOOAO 传动油散连接油路 Transmission oil radiator connecting pipeline
| 1 | 9D550-32B000001AO | 较接螺栓 Joint bolt | 1 |
| 2 | JBT982-22 | 组合密封垫圈 compound seal washer | 4 |
| 3 | 9D650-31A000010A0 | 较接螺栓 Joint bolt | 1 |
| 4 | 9D652-32A060000A0 | 管夹 2 clip 2 | 5 |
| 5 | GBT16674.1-M8X16-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 5 |
| 6 | QLWZG056.2-0122650 | 24。锥软管总成 24。taper hose assembly | 1 |
| 7 | 9D652-32A010000A0 | 油散进油软管 。il radiator inlet hose | 1 |
| 8 | 9D650-32A000001A0 | 变矩器出油接头 converter oil outlet joint | 1 |
| 9 | JBT982-24 | 组合密封垫圈 compound seal washer | 1 |
| 10 | QLWZG056.3-0050450 | 24。锥软管总成 24。taper hose assembly | 1 |
| 11 | 9D550-32B000002A0 | 较接接头 Articulation joint | 2 |
9D65O-33AOOOOOOAO 传动系回油油路 Transmission system oil return pipeline
| 1 | 9D650—33A000001A0 | 变矩器回油接头 。il return joint of converter | 1 |
| 2 | 9D650—33A010000A0 | 接头体 Joint body | 1 |
| 3 | 9D650—33A000003A0 | 回油胶管 。il return hose | 1 |
| 4 | 9D650—33A000004A0 | 变速箱回油接头 。il return hose of gearbox | 1 |
| 5 | JBT982—27 | 组合密封垫圈 compound seal washer | 1 |
| 6 | JBT8870—d40 | 喉箍 Hoop | 2 |
| 7 | 9D650—33A000002A0 | 较接螺栓 Joint bolt | 1 |
| 8 | JBT982—24 | 组合密封垫圈 compound seal washer | 2 |
| 9 | 9F653—59B120000A0 | 片式管夹 Disc type clip | 1 |
| 9.1 | GBT93—8—A0P | 标准型弹赁垫圈 standard spring washer | 1 |
| 9.2 | 9F653—59B120100A0 | 管夹 clip | 1 |
| 9.3 | GBT5783—M8X16—8.8—A2L | 六角头螺栓 Hex bolt | 1 |
9D65O-34AOOOOOOBO 车轮总成 wheel assembly
| 1 | 9D650-34A020000A0 | 有内胎轮胎(17.5-25-12PR) Tyre with tube(17.5-25-12PR) | 1 |
| 2 | 9D650-34A010000B0 | 三件式轮鋼(14.00/1.5-25) Three-piece rim(14.00/1.5-25) | 1 |
| 3 | 9D650-34A020100A0 | 外胎 Tyre | 1 |
| 4 | 9D650-34A020200A0 | 内胎 Tube | 1 |
| 5 | 9D650-34A020300A0 | 垫带 Flap | 1 |
| 6 | 9D650-34A010100B0 | 轮鋼体焊合 Rim body weldment | 1 |
| 7 | 9D650-34A010002A0 | 外轮缘 。uter rim | 1 |
| 8 | 9D650-34A010001A0 | 锁圈 LocK ring | 1 |
9D651-35AOOOOOOAO 制动供压系统 Brake pressure system
| 1 | 9D651-35A020000A0 | 油水分离器出气管 Air outlet pipe of oil water seperator | 1 |
| 2 | 9F851-35A020000A0 | 油水分离器进气管 Air inlet pipe of oil water seperator | 1 |
| 3 | 9B650-35A040000A0 | 卸荷阀 Relief valve | 1 |
| 4 | 9F850-35A050000A0 | 管夹 clip | 1 |
| 5 | 9D651-35A010000A0 | 空压机出气管 compressor air outlet pipe | 1 |
| 6 | 9D651-35A000002A0 | 空压机接头 compressor joint | 1 |
| 7 | GBT6177.1-M8-8-A2L | 六角法兰面螺母 Hex flange nut | 2 |
| 8 | GBT16674.1-M8X16-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 2 |
| 9 | 9D651-35A000001A0 | 固定板 Fixing plate | 1 |
| 10 | 9F850-36A000001A0 | 过渡接头 Transit joint | 1 |
| 11 | GBT3452.1-13.2X1.80G-70 | 液压气动用 。形橡胶密封圈 Hydraulic pneumatic 。-ring | 1 |
| 12 | GBT5783-M10X25-8.8-A3L | 六角头螺栓 Hex bolt | 2 |
| 13 | 9D651-35A000003A0 | 油水分离器支座 。il water seperator bracket | 1 |
| 14 | 9F850-35A000003A0 | 过渡接头 Transit joint | 1 |
9D650-36AOOOOOOBO 制动控制系统 Brake control system
| 1
2 3 4 5 6 7 8 9 10 11 12 15 16 17 18 19 20 21 22 |
GBT3452.1-13.2X1.80G-70
9F850-36A100000A0 9F850-36A030000A0 9F850-36A000001A0 9F550-36A050000B0 GBT16674.1-M8X25-8.8-A2L GBT16674.1-M12X25-8.8-A2L GBT6177.1-M12-8-A3L 9D650-36A030000A0 9F850-36A040000A0 9D650-36A020000A0 9F850-62A000001A0 QLWZG070.2-0061300 9D650-36A070000A0 9D652-36A000001A0 9D550-36B000001A0 9F653-36A130000A0 QLWZG070.3-0061080 9D650-36A010000A0 GBT16674.1-M12X20-8.8-A2L |
液压气动用 O 形橡胶密封圈
可调接头 安全阀 过渡接头 脚制动阀 六角法兰面螺栓 六角法兰面螺栓 六角法兰面螺母 加力泵支座 放水阀 空气加力泵 扎带 ZD200X5 平面密封聚氨酷软管总成 前加力泵制动管 较接接头 组合密封垫圈 测压接头 平面密封聚氨酷软管总成 储气筒 六角法兰面螺栓 |
Hydraulic pneumatic O_ring
Adjustable joint safety valve Transit joint Foot brake valve Hex flange bolt Hex flange bolt Hex flange nut compressor bracket Water bleeding valve Air compressor Lock cable ties ZD200X5 Hose assembly Front compressor brake pipe Articulation joint compound seal washer pressure measuring joint Hose assembly Air holder Hex flange bolt |
7
4 1 3 1 4 10 4 2 1 2 2 1 1 1 2 1 2 1 4 |
B00951+9D650-36A020000A0 空气加力泵 wuhu shengli air compressor
| 1 | B00951+SL209FT-3510010 | 气缸总成 Air cylinder assembly | 1 |
| 2 | GBT93-8-A3L | 标准型弹赁垫圈 Standard spring washer | 6 |
| 3 | GBT6170-M8-8-A2L | 1 型六角螺母 Type 1 hex nut | 6 |
| 4 | B00951+9D650-36A020000A0-XLB | 空气加力泵修理包 Air compressor repair kits | 1 |
| 4.1 | B00951+HFc6853-3510031 | 气活塞皮圈 piston leather ring | 1 |
| 4.2 | B00951+ZL20A-3510031 | 中心密封圈 central seal ring | 1 |
| 4.3 | B00951+JN162-3515025 | 。形密封圈 。-ring | 1 |
| 4.4 | GBT3452.1-17X2.65G-90 | 液压气动用 。形橡胶密封圈 Hydraulic pneumatic 。-ring | 1 |
| 4.5 | B00951+SL209-3510041 | 液压皮圈 Hydraulic leather ring | 1 |
| 5 | B00951+SL209-3510020 | 推杆活塞总成(除气活塞皮圈) push rod piston assembly (except piston leather ring) | 1 |
| 6 | B00951+SL209-3510031 | 回位弹赁 Retraction spring | 1 |
| 7 | GBT893.1-30 | 孔用弹性挡圈 circlip for hole | 1 |
| 8 | B00951+ZL20A-3510032 | 垫圈 washer | 1 |
| 9 | B00951+HFc6853-3510039 | 。形密封圈 。-ring | 1 |
| 10 | B00951+SL209FT-3510022 | 连接盖 connecting cover | 1 |
| 11 | GBT5783-M8X25-10.9-A3L | 六角头螺栓 Hex bolt | 6 |
| 12 | GBT893.1-25 | 孔用弹性挡圈 circlip for hole | 1 |
| 13 | B00951+SL209-3510050 | 推杆座总成 push rod seat assembly | 1 |
| 14 | B00951+STR-1604020 | 呼吸器总成 Breather assembly | 1 |
| 15 | B00951+SL509-3510040 | 储油杯总成 。il holder assembly | 1 |
| 16 | B00951+XM60A-35100031 | 骨架矩形圈 Framework rectangular ring | 1 |
| 17 | B00951+SL209FT-3510023 | 液压缸体 Hydraulic cylinder body | 1 |
| 18 | B00951+DL10TB-3510014 | 放气螺钉 Air bleeding screw | 1 |
| 19 | GBT93-10-A3L | 标准型弹赁垫圈 Standard spring washer | 5 |
| 20 | GBT5783-M10X35-10.9-A3L | 六角头螺栓 Hex bolt | 3 | |
| 21 | B00951+SL209-3510042 | 液压活塞 Hydraulic piston | 1 | |
| 22 | GBT5783-M10X25-10.9-A3L | 六角头螺栓 Hex bolt | 2 | |
| 23 | B00951+SL209FTA-3510021 | 安装支架 Installation bracket | 1 |
B00190+9D650-36A020000A0 重庆汇浦空气加力泵 chongqing Huipu air compressor
| 1 | B00190+HP3.5—40—21B | 气缸 Air cylinder | 1 |
| 2 | B00190+9D650—36A020000A0—XLB | 空气加力泵修理包 Air compressor repair kits | 1 |
| 2.1 | B00190+HP3.5—40—22 | 气缸密封圈 Air cylinder seal ring | 1 |
| 2.2 | B00190+HP3.5—40—35 | 防尘圈 Dustproof ring | 1 |
| 2.3 | B00190+HP3.5—40—39 | 导向环 Guide ring | 1 |
| 2.4 | B00190+HP3.5—40—38 | Y 型圈 Y—ring | 1 |
| 2.5 | B00190+HP3.5—40—36 | 活塞杆密封圈 Piston rod seal ring | 1 |
| 2.6 | B00190+HP3.5—40—39 | 导向环 Guide ring | 1 |
| 2.7 | B00190+HP3.5—40—40 | 。型圈 。—ring | 1 |
| 2.8 | B00190+HP1604DA—00—31 | 。型圈 。—ring | 1 |
| 2.9 | B00190+HP1604DA—00—31 | 。型圈 。—ring | 1 |
| 2.10 | B00190+HP3.5—40—02 | 端盖 。型圈 End cover joint 。—ring | 1 |
| 3 | B00190+HP3.5—40—23 | 气缸活塞体 Air cylinder piston body | 1 |
| 4 | GBT70.1—M12X30—8.8—A2L | 内六角圆柱头螺钉 socket hexagon cap head screw | 1 |
| 5 | GBT93—12—A。P | 标准型弹赁垫圈 standard spring washer | 1 |
| 6 | B00190+HP3.5—40—24A | 推盘 Thrust disc | 1 |
| 7 | B00190+HP3.5—40—27 | 气缸回位弹赁 Air cylinder retraction spring | 1 |
| 8 | GBT93—8—A。P | 标准型弹赁垫圈 standard spring washer | 6 |
| 9 | GBT5783—M8X15—8.8—A3L | 六角头螺栓 Hex bolt | 6 |
| 10 | B00190+HP3.5—40—11 | 进油接头总成 。il inlet joint assembly | 1 |
| 11 | B00190+HP3.5—40—17 | 油杯体 。il cup body | 1 |
| 12 | B00190+HP3.5—40—12 | 螺母 M27X1.5 Nut M27X1.5 | 1 |
| 13 | B00190+HP3.5—40—16 | 油杯滤网 。il cup filter screen | 1 |
| 14 | B00190+HP3.5—40—14 | 油杯膜片 。il cup diaphragm | 1 |
| 15 | B00190+HP3.5-40-15 | 油杯盖 。il cup cover | 1 |
| 16 | B00190+HP3.5-40-28 | 活塞 Piston | 1 |
| 17 | B00190+HP3.5-40-01 | 端盖 End cover | 1 |
| 18 | B00190+HP3.5-40-03 | 本体 Body | 1 |
| 19 | B00190+HP.FC-01 | 呼吸螺栓 Breather bolt | 1 |
9D65O-37COOOOOOBO 驱动桥管路系统 Drive axle pipeline system
| 1 | 9D650-37B020000A0 | 桥制动管 Axle brake pipe | 4 |
| 2 | 9D650-37A010000A0 | 后加力泵制动管 Rear compressor brake pipe | 1 |
| 3 | 9D650-37A000002A0 | 三通 Tee | 2 |
| 4 | GBT16674.1-M8X25-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 2 |
| 5 | 9D650-37A000003A0 | 过渡接头 Transit joint | 4 |
| 6 | 9D550-36B000001A0 | 组合密封垫圈 compound seal washer | 6 |
| 7 | 9D650-37A000004A0 | 管夹 clip | 4 |
| 8 | GBT16674.1-M6X12-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 4 |
| 9 | 9D653-36A130000A0 | 测压接头 pressure measuring joint | 1 |
| 10 | 9D652-36A000001A0 | 较接接头 Articulation joint | 1 |
| 11 | 9D650-37A030000A0 | 管夹 clip | 1 |
| 12 | GBT16674.1-M8X16-8.8-A2L | 六角法兰面螺栓 Hex flange bolt | 1 |
| 13 | 9D650-37c000001A0 | 三通支座 Tee bracket | 1 |
| 14 | GBT6177.1—M8-8-A2L | 六角法兰面螺母 Hex flange nut | 1 |
